The ZCL Hall Effect IC is Optimized for BLDC Motor Control
The ZCL hall effect IC is a new generation of Hall effect ICs
that change the output signal at the point polarity changes (zero crossing point) and employs
the world’s first detection method optimized for
brushless DC motor control.
■S-576Z B Series (General-use)
High energy efficiency, reliability, low-noise performance and other characteristics make it ideal in consumer products that require granular control.
Three Advantages the ZCL Hall Effect IC Brings to Motor Design
- Rotation angle detection is not easily impacted by changes in magnetic flux
- [World’s Top Class] Compact and Low Profile Motor Housing
- Specifications defined for designer
<Applications>
- Robots (brushless DC motors for vertical movement and
operation of joints) - Electric power tools, cordless vacuum cleaners, etc.
■S-576Z R Series (General-use, -50℃ compatible)
Stable control of operation of physical infrastructure even at -50°C.
- Optimizes operation of physical infrastructure
- Creates a BLDC motor impervious to
temperature fluctuations or design tolerances - Specifications ideal for motors
<Applications>
- Infrastructure equipment, Outdoor brushless DC motor
（5G base station antennas, electric valve actuators）
■S-57TZ S Series (Automotive)
Ideal for applications that require high efficiency,
high reliability, and low noise.
Three Advantages the ZCL Hall Effect IC Brings to Motor Design
- Rotation angle detection is not easily impacted by changes in magnetic flux
- [World’s Top Class] Compact and Low Profile Motor Housing
- Specifications ideal for Automotive motor
<Applications>
-
Automotive BLDC motor
- Power sliding doors /power back doors operating when the ignition is off
